Description

Mineral insulated sensor with strengthened sheath suitable for measurement of liquids, semifluid masses or loose materials with high density or flow in conditions of great vibrations.

Files

pdf icon Catalog card pdf icon Manual / DTR

Contact with a consultant

Telephone: +48 (18) 330 10 06

Fax: +48 (18) 330 10 04

E-mail: [email protected]

Do you have a question?
product image
General Connection heads Compatible devices Additional accessories Contact form

Temperature range

  • -50÷550ºC        Pt100
  • -40÷700ºC        J
  • -40÷1000ºC      K



Specification

  • sensing element: Pt100/Pt500/Pt1000 resistor or J, K thermocouple
  • connection head type MA IP54, - 40÷100ºC
  • temperature transmitter can be mounted in a connection head
  • material: stainless steel 1.4541, 1.4571 and INCONEL



Mounting



connection heads

Controllers / Thermostats

Indicators

Recorders

plugs and sockets

protection tubes and thermowells

compression fittings

compensation cables

transmitters

welding adapters
